• Specs
• Diagonal Distance

14.96″ (380.1mm)

• Max Ascent Speed

6m/s (Normal Mode) 8m/s (Sport Mode)

• Max Descent Speed

6m/s (Normal Mode) 6m/s (Sport Mode)

• Max Flight Speed (at sea level, no wind)

15m/s (Normal Mode) Forward: 21m/s, Side: 20m/s, Backward: 19m/s (Sport Mode)

• Max Wind Speed Resistance

12m/s

• Max Take-off Altitude Above Sea Level

6000m (without payload)

• Max Flight Time (no wind)

45mins

• Max Hover Time (no wind)

38mins

• Max Flight Distance

32km

• Max Tilt Angle

30 Degree (Normal Mode) 35 Degree (Sport Mode)

• Max Angular Velocity

200 Degree /s

• GNSS

GPS+Galileo+BeiDou+GLONASS (GLONASS is supported only when the RTK module is enabled)

• Hovering Accuracy

Vertical: +/-0.1m (with Vision System); +/-0.5m (with GNSS); +/-0.1m (with RTK) Horizontal: +/-0.3m (with Vision System); +/-0.5m (with High-Precision Positioning System); +/-0.1m (with RTK)

• Operating Temperature Range

-10 Degree to 40 Degree C (14 Degree to 104 Degree F)

• Motor Model

2008

• Propeller Model

9453F Propellers for Enterprise

• Beacon

Built into the aircraft

• Battery Info

Required, included

• Battery Material

Lithium ion

• Battery Type

Non-universal

• Battery Quantity

1

• Dimensions (L x W x H)

Folded (without propellers): 8.7 x 3.79 x 3.55″ (221 x 96.3 x 90.3mm) Unfolded (without propellers): 13.68 x 11.14 x 4.24″ (347.5 x 283 x 107.7mm)

• Weight

With propellers, without accessories: 32.45 oz (920g) Max Takeoff: 2.31 lbs (1.05kg)

• Wide CameraJump to…
• Sensor

1/2″ CMOS, Effective pixels: 48 MP

• Lens

FOV: 84 Degree Format Equivalent: 24mm Aperture: f/2.8 Focus: 1m to Infinite

• ISO Range

100-25600

• Shutter Speed

Electronic Shutter: 8-1/8000s

• Max Image Size

8000 x6000

• Still Photography Modes

Single: 12 MP/48 MP Timed: 12 MP/48 MP JPEG: 2/3/5/7/10/15/20/30/60 s Panorama: 12 MP (raw image); 100 MP (stitched image) Smart Low-light Shooting: 12 MP

• Video Resolution

H.264 4K: 3840 x 2160@30fps FHD: 1920 x 1080@30fps

• Bitrate

4K: 85 Mbps FHD: 30 Mbps

• Supported File Formats

exFAT

• Photo Format

JPEG

• Video Format

MP4 (MPEG-4 AVC/H.264)

• Tele CameraJump to…
• Sensor

1/2″ CMOS, Effective pixels: 12 MP

• Lens

FOV: 15 Degree Format Equivalent: 162mm Aperture: f/4.4 Focus: 3m to Infinite

• ISO Range

100-25600

• Shutter Speed

Electronic Shutter: 8-1/8000 s

• Max Image Size

4000 x 3000

• Photo Format

JPEG

• Video Format

MP4 (MPEG-4 AVC/H.264)

• Still Photography Modes

Single: 12 MP Timed: 12 MP JPEG: 2/3/5/7/10/15/20/30/60 s Smart Low-light Shooting: 12 MP

• Video Resolution

H.264 4K: 3840 x2160@30fps FHD: 1920 x1080@30fps

• Bitrate

4K: 85 Mbps FHD: 30 Mbps

• Digital Zoom

8x (56x hybrid zoom)

• Thermal CameraJump to…
• Thermal Imager

Uncooled VOx Micro bolometer

• Pixel Pitch

12 microm

• Frame Rate

30 Hz

• Lens

DFOV: 61 Degree Format Equivalent: 40 mm Aperture: f/1.0 Focus: 5 m to Infinite

• Sensitivity

<=50 mk@F1.1

• Temperature Measurement Method

Spot Meter, Area Measurement

• Temperature Measurement Range

-4 Degree to 302 Degree F (-20 Degree to 150 Degree C, High Gain Mode) 32 Degree to 932 Degree F (0 Degree to 500 Degree C, Low Gain Mode)

• Palette

White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/Fulgurite/Rainbow 1/Rainbow 2

• Photo Format

JPEG (8-bit) R-JPEG (16-bit)

• Video Resolution

640 x 512@30fps

• Bitrate

6 Mbps

• Video Format

MP4 (MPEG-4 AVC/H.264)

• Still Photography Modes

Single: 640 x512 Timed: 640 x512 JPEG: 2/3/5/7/10/15/20/30/60 s

• Digital Zoom

28x

• Infrared Wavelength

8-14 microm

• Infrared Temp. Measurement Accuracy

+/-2 Degree C or +/-2% (using the larger value)

• GimbalJump to…
• Stabilization

3-axis (tilt, roll, pan)

• Mechanical Range

Tilt: -135 Degree to 45 Degree Roll: -45 Degree to 45 Degree Pan: -27 Degree to 27 Degree

• Controllable Range

Tilt: -90 Degree to 35 Degree Pan: Not controllable

• Max Control Speed (tilt)

100 Degree /s

• Angular Vibration Range

+/-0.007 Degree

• SensingJump to…
• Type

Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft.

• Forward

Measurement Range: 0.5-20 m Detection Range: 0.5-200 m Effective Sensing Speed: Flight Speed <=15m/s FOV: Horizontal 90 Degree , Vertical 103 Degree

• Backward

Measurement Range: 0.5-16 m Effective Sensing Speed: Flight Speed <=12m/s FOV: Horizontal 90 Degree , Vertical 103 Degree

• Lateral

Measurement Range: 0.5-25 m Effective Sensing Speed: Flight Speed <=15m/s FOV: Horizontal 90 Degree , Vertical 85 Degree

• Upward

Measurement Range: 0.2-10 m Effective Sensing Speed: Flight Speed <=6m/s FOV: Front and Back 100 Degree , Left and Right 90 Degree

• Downward

Measurement Range: 0.3-18 m Effective Sensing Speed: Flight Speed <=6m/s FOV: Front and Back 130 Degree , Left and Right 160 Degree

• Operating Environment

Forward, Backward, Lateral, and Upward: Surface with a clear pattern and adequate lighting (lux >15) Downward: Diffuse reflective surface with diffuse reflectivity>20% (e.g. walls, trees, people) and adequate lighting (lux >15)

• Video TransmissionJump to…
• Video Transmission System

DJI O3 Enterprise Transmission

• Live View Quality

Remote Controller: 1080p/30fps

• Operating Frequency

2.400-2.4835 GHz 5.725-5.850 GHz

• Max Transmission Distance

FCC: 15 km CE: 8 km SRRC: 8 km MIC: 8 km (Unobstructed, free of interference)

• Max Transmission Distance (Obstructed)

Strong Interference (dense buildings, residential areas, etc.): 1.5-3 km (FCC/CE/SRRC/MIC) Medium Interference (suburban areas, city parks, etc.): 3-9 km (FCC), 3-6 km (CE/SRRC/MIC) Low Interference (open spaces, remote areas, etc.): 9-15 km (FCC), 6-8 km (CE/SRRC/MIC)

• Max Download Speed

15 MB/s (with DJI RC Pro Enterprise)

• Latency

Approx. 200 ms (depending on environmental conditions and mobile device)

• Antenna

4x Antennas, 2T4R

• Transmission Power (EIRP)

2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE)

• RC Pro EnterpriseJump to…
• Model

RM510B

• Video Transmission System

DJI O3 Enterprise Transmission

• Max Transmission Distance

FCC: 15km CE/SRRC/MIC: 8km (Unobstructed, free of interference)

• Video Transmission Operating Frequency

2.400-2.4835 GHz 5.725-5.850 GHz

• Antenna

4x Antennas, 2T4R

• Video Transmission Transmitter Power

(EIRP) 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <23 dBm (SRRC)

• Wi-Fi Protocol

802.11 a/b/g/n/ac/ax Support 2 x2 MIMO Wi-Fi

• Wi-Fi Operating Frequency

2.400-2.4835 GHz 5.150-5.250 GHz 5.725-5.850 GHz

• Wi-Fi Transmitter Power (EIRP)

2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.1 GHz: <26 dBm (FCC), <23 dBm (CE/SRRC/MIC) 5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE)

• Bluetooth Protocol

Bluetooth 5.1

• Bluetooth Operating Frequency

2.400-2.4835 GHz

• Bluetooth Transmitter Power (EIRP)

< 10 dBm

• Screen Resolution

1920 x 1080

• Screen Size

5.5″ (139.7mm)

• Screen

60 fps

• Brightness

1,000 nits

• Touchscreen Control

10-point multi-touch

• Battery

Li-ion (5000 mAh @ 7.2 V)

• Charging Type

Recommended to be charged with the included DJI USB-C Power Adapter (100W) or USB charger at 12 V or 15 V

• Rated Power

12 W

• Storage Capacity

Internal Storage (ROM): 64GB Supports a microSD card for expanded capacity.

• Charging Time

Approx. 1 hour 30 minutes (with the included DJI USB-C Power Adapter (100W) only charging the remote controller or a USB charger at 15 V) Approx. 2 hours (with a USB charger at 12 V) Approx. 2 hours 50 minutes (with the included DJI USB-C Power Adapter (100W) charging the aircraft and remote controller simultaneously)

• Operating Time

Approx. 3 hours

• Video Output Port

Mini-HDMI port

• Operating Temperature Range

14 Degree to 104 Degree F (-10 Degree to 40 Degree C)

• Storage Temperature

-22 Degree to 140 Degree F (-30 Degree to 60 Degree C) (within one month) -22 Degree to 113 Degree F (-30 Degree to 45 Degree C) (one to three months) -22 Degree to 95 Degree F (-30 Degree to 35 Degree C) (three to six months) -22 Degree to 77 Degree F (-30 Degree to 25 Degree C) (more than six months)

• Charging Temperature

41 Degree to 104 Degree F (5 Degree to 40 Degree C)

• Supported DJI Aircraft

DJI Mavic 3T

• GNSS

GPS+Galileo+GLONASS

• Dimensions (L x W x H)

Antennas folded and controller sticks unmounted: 7.21 x 5.4 x 1.87″ (183.27 x 137.41 x 47.6mm) Antennas unfolded and controller sticks mounted: 7.21 x 8 x 2.35″ (183.27 x 203.35 x 59.84mm)

• Weight

Approx. 23.98 oz (680g)

• StorageJump to…
• Supported Memory Cards

Aircraft: U3/Class10/V30 or above is required. A list of recommended microSD cards can be found below.

• Recommended microSD Cards

Remote Controller: SanDisk Extreme PRO 64GB V30 A2 microSDXC SanDisk High Endurance 64GB V30 microSDXC SanDisk Extreme 128GB V30 A2 microSDXC SanDisk Extreme 256GB V30 A2 microSDXC SanDisk Extreme 512GB V30 A2 microSDXC Lexar 667x 64GB V30 A2 microSDXC Lexar High-Endurance 64GB V30 microSDXC Lexar High-Endurance 128GB V30 microSDXC Lexar 667x 256GB V30 A2 microSDXC

• Recommended microSD Cards (Contd.)

Lexar 512GB V30 A2 microSDXC Samsung EVO Plus 64GB V30 microSDXC Samsung EVO Plus 128GB V30 microSDXC Samsung EVO Plus 256GB V30 microSDXC Samsung EVO Plus 512GB V30 microSDXC Kingston Canvas Go! Plus 128GB V30 A2 microSDXC Kingston Canvas React Plus 128GB V90 A1 microSDXCAircraft: SanDisk Extreme 32GB V30 A1 microSDHC SanDisk Extreme PRO 32GB V30 A1 microSDHC

• Recommended microSD Cards (Contd..)

SanDisk Extreme 512GB V30 A2 microSDXC Lexar 1066x 64GB V30 A2 microSDXC Kingston Canvas Go! Plus 64GB V30 A2 microSDXC Kingston Canvas React Plus 64GB V90 A1 microSDXC Kingston Canvas Go! Plus 128GB V30 A2 microSDXC Kingston Canvas React Plus 128GB V90 A1 microSDXC Kingston Canvas React Plus 256GB V90 A2 microSDXC Samsung PRO Plus 256GB V30 A2 microSDXC

• BatteryJump to…
• Capacity

5000 mAh

• Standard Voltage

15.4 V

• Max Charging Voltage

17.6 V

• Type

LiPo 4S

• Chemical System

LiCoO2

• Energy

77 Wh

• Charging Temperature

41 Degree to 104 Degree F (5 Degree to 40 Degree C)

• Weight

11.83 oz (335.5g)

• ChargerJump to…
• Input

100-240 V (AC Power), 50-60 Hz, 2.5 A

• Output Power

100 W

• Output

Max. 100 W (total) When both ports are used, the maximum output power of each interface is 82 W, and the charger will dynamically allocate the output power of the two ports according to the load power.

• Charging HubJump to…
• Input

USB-C: 5-20 V, 5.0 A

• Output

Battery Port: 12-17.6 V, 8.0 A

• Rated Power

100 W

• Charging Type

Three batteries charged in sequence

• Charging Temperature Range

41 Degree to 104 Degree F (5 Degree to 40 Degree C)

• RTK ModuleJump to…
• Interface

USB-C

• Power

Approx. 1.2 W

• RTK Positioning Accuracy

RTK Fix: Horizontal: 1cm + 1 ppm; Vertical: 1.5cm + 1 ppm

• Dimensions (L x W x H)

1.97 x 1.58 x 2.6″ (50.2 x 40.2 x 66.2mm)

• Weight

0.84 oz (24g) ( +/-2g)

• SpeakerJump to…

Interface USB-C Rated Power 3 W Max Volume 110 dB @ 1m Effective Broadcast Distance 100m @ 70 dB Bitrate 16 Kbps/32 Kbps Operating Temperature Range 14 Degree to 104 Degree F (-10 Degree to 40 Degree C) Dimensions (L x W x H) 4.49 x 3.22 x 2.15″ (114.1 x 82.0 x 54.7mm) Weight 2.99 oz (85g) ( +/-2g)
