Autel EVO II 640T (Thermal) Enterprise Rugged Bundle

₨1,634,000

Are you looking for Repair or Exchange?

Categories: , , Tags: , , , , , Brand:

Note: Due to shortage and currency fluctuation in Pakistan, kindly confirm price and availability before ordering!

Thermal Camera

Infrared camera sensor Uncooled VOx Microbolometer Sensor resolution 640×512 Pixel pitch 12 microm Wavelength range 8-14 microm focal length 13mm FOV H33 Degree V26 Degree Zoom 1 – 8x Camera resolution Infrared mode: 640 x 512 Picture in Picture: 1920 x 1080, 1280 x 720 Photo shooting mode Single shooting, continuous shooting, time-lapse shooting Video Resolution 640 x 512 30fps Video format MOV / MP4 (support H.264/H.265) Temperature measurement accuracy +/-3 Degree C or +/-3% of reading (whichever is greater) @ambient temperature -20 Degree C-60 Degree C Temperature range High gain mode: -20 Degree to +150 Degree C Low gain mode: 0 Degree to +550 Degree C Accurate temperature measurement Range 2-20 meters

Camera

Image Sensor 1/2″ CMOS Pixels 48MP Perspective 79 Degree Lens EFL: 25.6 mm Aperture: f/2.8-f/11 Focus Distance: 0.5m to any distance (with autofocus mode) ISO Range Video: 100-6400 (auto) Photo: 100-3200 (auto) Zoom 1-8x (Max 4x lossless) Still Photography Modes Single Shot Burst: 3/5 shots Auto Exposure Bracketing (AEB) Time-lapse: 3/5 shots Still Photography Resolution 8000 x 6000 (4:3) 7680 x 4320 (16:9) 4000 x 3000 (4:3) 3840 x 2160 (16:9) Video Format MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265) Video Resolution 8K 7680 x 4320 p25/p24 6K 5760 x 3240 p30/p25/p24 4K 3840 x 2160 p60/p50/p48/p30/p25/p24 2.7K 2720 x 1528 p120/p60/p50/p48/p30/p25/p24 1080P 1920 x 1080 p120/p60/p50/p48/p30/p25/p24 Max Bitrate 120Mbps

AircraftJump to…

Aircraft Battery 7100 mAh Max Flight Time (standard) EVO II Dual (640) 38min EVO II Dual (320) 40min Max Hovering Time (standard) EVO II Dual (640) 33min EVO II Dual (320) 35min Max Level Flight Speed (Standard) 45mph (20 m/s) (Ludicrous) Max Ascent Speed 18mph (8 m/s) (Ludicrous) Max Descent Speed 9 mph (4 m/s) (Ludicrous) Max Service Ceiling Altitude 4.3 miles (7000 m) MSL Max Wind Resistance Force 8 wind Operating Environment Temp 14-104 Degree F (-10-40 Degree C) Working Frequency 2.4-2.4835GHz Transmission Power 2.4-2.4835GHz FCC/ISED:<=27dBm SRRC/CE/MIC/RCM:<=20dBm Hover Precision Vertical: +/- 0.1m (with visual positioning in normal operation) +/- 0.5m (with GPS in normal operation) Horizontal: +/- 0.3m (with visual positioning in normal operation) +/- 1.5m (with GPS in normal operation)

Sensing System

Sensing System Type Omnidirectional Binocular Sensing System Forward Accurate Measuring Range: 0.5 – 20m Detection Range: 0.5 – 40m Effective Sensing Speed: < 15 m/s FOV: Horizontal: 60 Degree , Vertical: 80 Degree Backward Accurate Measuring Range: 0.5 – 16m Detection Range: 0.5 – 32m Effective Sensing Speed: < 12 m/s FOV: Horizontal: 60 Degree , Vertical: 80 Degree Upward Accurate Measuring Range: 0.5 – 12m Detection Range: 0.5 – 24m Effective Sensing Speed: < 6 m/s FOV: Horizontal: 65 Degree , Vertical: 50 Degree Downward Accurate Measuring Range: 0.5 – 11m Detection Range: 0.5 – 22m Effective Sensing Speed: < 6 m/s FOV: Horizontal: 100 Degree , Vertical: 80 Degree Sides Accurate Measuring Range: 0.5 – 12m Detection Range: 0.5 – 24m Effective Sensing Speed: < 10 m/s FOV: Horizontal: 65 Degree , Vertical: 50 Degree Service Environment Textured/patterned ground and adequate illumination (> 15 lux, normal indoor environment with fluorescent lamp on) Upward: diffuse reflecting surface with reflectivity above 20% (wall, tree, human, etc.) Downward: textured/patterned ground and adequate illumination (> 15 lux, normal indoor environment with fluorescent lamp on) Upward: diffuse reflecting surface with reflectivity above 20% (wall, tree, human, etc.)

Gimbal

Operation Range Pitch: -135 Degree to +45 Yaw: -100 Degree to +100 DegreePitch: -90 Degree to +30 Degree Yaw: -90 Degree to +90 Degree Stability More Stable with 3 Axies Max Control Speed (Tilt) 300 Degree /s Angular Vibration Range (Degree) +/-0.005 Degree

Remote Controller and Transmission

Max Signal Transmission Distance 5.5 miles (9km) FCC, 3.1 miles (5km) CE Working Frequency 2.4-2.4835GHz Transmission Power 2.4-2.4835GHz FCC/ISED:<=27dBm SRRC/CE/MIC/RCM:<=20dBm Real-Time Transmission Quality 720p@30fps / 1080p@30fps Max Bitrate of Real-time Transmission 40Mbps Remote Controller Battery 5000mAh Operating Hours 3h Charging Time 2h Fast Charging Display 3.26-inch OLED screen 854 (W) x 480 (H) pixels Preview video without the need for connecting to a mobile phone

Charger

Input 100-240 V, 50/60 Hz, 1.5A Output 13.2 V – 5 A 5V-3A 9V-2A 12V-1.5A Voltage 13.2 +/- 0.1 V Rated Power 66 W

APPJump to…

iOS Autel Explorer Android Autel Explorer

StorageJump to…

SD Storage Standard: 32 GB, max. support 256GB ¼ UHS-3 rating required ¼ Internal Storage 8GB

Battery

Battery (mAh) 7100mAh Voltage (V) 11.55 Transmission Power (2.4G) 13.2 Battery Type LiPo 3S Battery Type LiPo 3S Battery Energy 82Wh Weight 12.8 oz (365g) Charging Temperature Range ( Degree C) 5-45 Degree C (41-113 Degree F) Storage Temperature & Humidity -10-30 Degree C (14-86 Degree F) 65 +/-20%RH Recommended Storage Temperature 22-28 Degree C (71.6-82.4 Degree F) Max Charging Power Consumption (W) 93W Charging Time 90min Battery Info Required, Included Battery Material Lithium Battery Quantity 1

Physical

Diagonal Wheelbase 15.6″ (397 mm) Takeoff Weight 2.5 lbs (1150g) Max: 4.4 lbs (2000g)

Description

Autel EVO II 640T (Thermal) Enterprise Rugged Bundle

Buy Autel EVO II 640T (Thermal) Enterprise Rugged Bundle from us at the best prices Autel drones in Pakistan and enjoy our nationwide free delivery, customers from Karachi, Lahore, Islamabad, Quetta, Peshawar, Multan, Faisalabad, Sialkot, Hyderabad can get deliveries within 24 hours.

Power. Efficiency. Reliability

The Most Compact and Advanced Thermal Drone

Autel Robotics new generation thermal camera

Resolutions up to 640×512 enable EVO II Dual pilots to capture subjects with great detail from up to 100 meters – 4x farther than any aircraft of its class. The 30Hz refresh rate produces smooth dynamic thermal movement by matching thermal images to video frame rate.

Multiple Temperature Measurement Modes, Professional Analysis Tool Central Temperature Measurement, Spot Temperature Measurement, Regional Temperature Measurement

Central temperature measurement: View a real-time display of the temperature in the center area of the screen.

• Spot temperature measurement: Tap the screen, and the temperature of the selected object will be displayed in real-time.

• Regional temperature measurement: Get a dynamic view of the average temperature, maximum temperature, and minimum temperature displayed in a selected area.

Autel Robotics EVO II Dual 640T



Powerful Infrared Thermal Analysis Tool.

Autel IR PC Tool:

This free temperature measurement analysis tool is developed for the 640T, and enables users to quickly import images, edit and analyze temperature measurements, and to generate detailed reports for sharing and collaboration.

Temperature Alarm, Isotherm, Image Enhancement •

Temperature alarm: Monitors the screen temperature in real time. The system prompts the user when the temperature reaches a set threshold.

• Isotherm: Set a temperature range and the system will detect any objects within the temperature range specified.

• Image enhancement: Supports real-time adjustment of image brightness, contrast, and image details. The system will highlight any objects within the temperature target.

• 640×512 Resolution

• Refresh rate: 30Hz

• Picture-in-picture mode

• 10 Thermal Color Palettes

Powerful Infrared Thermal Analysis Tool.



Maximum Efficiency In All Viewing Conditions.

EVO II Dual supports up to 10 thermal palettes to cope with a variety of complex shooting environment and mission scenarios.

Picture-in-Picture Mode

The thermal image is integrated into the standard RGB image at the same time. This allows the user to obtain both visual and thermal data at the same time and allows for easier positioning and subject tracking.

8K allows even the smallest detail to be captured and preserved 8K Video, unmatched clarity

Autel Evo II Dual records in resolutions up to 7680×4320. With 4 times as many pixels compared to 4k (and 16 times compared to HD), 8k videos redefine image clarity and depth.

48MP Camera

The Evo II Dual’s 48MP Sensor captures every forensic-relevant detail to assist in precise evidence capture. Both thermal and RGB images are provided with embedded Metadata making the EVOII Dual the ultimate Public Safety tool.

4X Lossless zoom

The high resolution provides the ability to zoom deep into a scene and crop an image or video to 4k without any loss in quality. Capture a scene, zoom in, and reframe your shots with ease.

4K HDR for greater dynamic range

4K HDR offers greater detail in highlights and shadows, providing higher-quality images from the most demanding environments.

360 Degree Obstacle Avoidance

Equipped with 19 groups of sensors including 12 visual sensors, the main camera, ultrasound, IMUs and other sensors enable building of three-dimensional maps and path planning in real time.

Dynamic Track 2.0

EVO II can model location and speed of targets simultaneously, predict their trajectory accurately, and track them continuously while identifying up to 64 objects at the same time.

Maximum Efficiency In All Viewing Conditions.



Applications:

• Line Inspections: Reduce costs, increase safety, and improve inspection workflow.

• Firefighting: Locate hotspots, provide overwatch, and shorten response times.

• Law enforcement:

Perform overwatch, accident scene reconstruction, forensics, and crowd monitoring.

• Search & Rescue: Identify subjects, reduce response times and maximize search area with automated mission planning.

• Chemical: Inspect plants more efficiently while also improving worker’s safety, and lowering inspection costs.

• Increase solar farm inspection efficiency with automated mission planning to reduce field time and allow for thermal inspection via thermal payload and 3rd party software to identify defects or faulty hardware.

Features.

  • 640×512 Resolution
  • Refresh rate: 30Hz
  • Picture-in-picture mode
  • 10 Thermal Color Palettes
  • 8K Video, unmatched clarity
  • 48MP Camera
  • 4X Lossless zoom
  • 4K HDR for greater dynamic range
  • 38 minutes battery life
  • 5.5 miles transmission range
  • Level 8 wind resistance
  • 45 mph max flight speed
  • Magnesium Alloy Structure
  • Real-time video distribution
  • LiveDeck enables pilots to share live, real-time aerial video across public or private networks, sharing data with Command Posts, stakeholders, or online presentations.
  • Open SDK
  • Create customized services, applications, access, and other features
  • 38 minutes battery life
  • 5.5 miles transmission range
  • Level 8 wind resistance
  • 45 mph max flight speed
  • Magnesium Alloy Structure
